The Halo P 3 Preamplifier continues our tradition of incredible sound
and tremendous value while adding stunning industrial design. With features like
direct balanced XLR inputs and outputs, a unique switchable phono/line input
stage, and a remote control that also operates the T 3 Tuner, the P 3 will
provide you with hours of musical enjoyment. The beautiful looks and amazing
sound quality of this two-channel preamp make it suitable for both the first
time high performance listener and the seasoned audiophile.
P 3 Features:
|
6 line inputs, one input switchable to
MM phono |
|
Relay switched direct inputs: balanced
and unbalanced |
|
External processor send and receive
loop |
|
Balanced XLR and unbalanced RCA outputs |
|
Vacuum fluorescent status display |
|
Defeatable bass and treble controls |
|
Enormous encapsulated toroid power
transformer |
|
Dual layer glass epoxy circuit boards |
|
High resolution stereo headphone
circuit |
|
RS-232 control port and ground lift
switch |
|
External IR input and loop output jacks |
|
Two 12v triggers; 1 input and 1 loop
output |
|
Gold-plated RCA jacks |
|
Remote control also operates T 3 Tuner |
|
Robust 2u Chassis, rack mounting
adapter available |
|
Parasound’s 10 years parts, 5 years
labor warranty |
|
P 3 Specs:
|
Frequency response: 5 Hz - 55 kHz,
+0/-1 dB, full output |
|
Total harmonic distortion: < 0.01% 1
kHz; < 0.03% 20 kHz |
|
IM distortion: < 0.03% |
|
Maximum output: > 8 V before
clipping |
|
Input impedance: line input 30 kW;
phono 47 kW |
|
Output impedance: 60 W |
|
Input sensitivity: line inputs 150 mV,
+/- 5%; phono 2 mV |
|
Max input level: 10.5 V before clipping |
|
S/N ratio: |
|
|
line input > 92 dB, A-weighted, ref 1 V output |
|
|
line input > 84 dB, unweighted, ref 1 V output |
|
|
phono > 72 dB, ref .5 mV input |
|
Crosstalk: > 55 dB, 20 kHz |
|
Channel level matching: < 0.1 dB |
|
Voltage: Switchable for 110V - 120V or
220V – 240V operation |
|
Dimensions: 17-1/4" w x
4-1/8" h x 13-3/4" d, 3-5/8" h without feet |
|
Net weight: 16 lbs. |
|
|
